Unique CORN lens array speciaized for outdoor lighting, bright, even and sot like the lighting of football stadium, itMakes people cozy dunng heavy duty jobs in the open held
Unique asymmetric beam pattern returnsmore illumination on the ground. No glare.
EMC level ClSPR 25 Class 3
Vibration resistance:up to 15.3Grms.
Shock resistance: up to 60G.
| Model: | E2197 | |
| Functions, Homologation | ||
| Functions: | Asymmetric lens pattern | |
| Homologations | ECE R10 | |
| Optical & Electric Features | ||
| LED Type: | 24PCS 5050LEDs | |
| Color Temp: | 5500~6500K | |
| Raw Lumen: | 25200LM | |
| Effective Lumen: | 9600LM | |
| Luminous Efficacy: | 96LM/W | |
| Raw Power: | 144W | |
| Effective Power: | 100W | |
| Current Draw: | 8.33A@12V‚ 4.17A@24V | |
| Electromagnetic Features | ||
| EMC Grade: | CISPR 25 Class 3 | |
| Operating Voltage: | 10V~30V | |
| Connector: | DT / AMP/ Cable (Optional) | |
| ATM: | Active thermal management | |
| Mechanical Features | ||
| Size: | 110X110X 130.5mm | |
| Housing Material: | Aluminium Alloy | |
| Lens Material: | Anti-UV PC | |
| Bracket: | Stainless Steel | |
| IP Rate: | IP67, IP6K9K | |
| Work Temp: | -40~+50°C | |
| So this is Life | ||
| Life Time: | >30,000H | |
