| Model: | E-WL-501 | |
| Functions, Homologation | ||
| Functions: | 80°Flood Beam or 40°Spot Beam | |
| Homologations | ECE R10 | |
| Optical & Electric Features | ||
| LED Type: | 18pcs SMD LED(s) | |
| Color Temp: | 5000~6500K | |
| Raw Lumen: | 3960LM | |
| Effective Lumen: | 2195.3LM | |
| Luminous Efficacy: | 85LM/W | |
| Raw Power: | 54W | |
| Effective Power: | 25.56W | |
| Current Draw: | 2.13A@12V; 1.065A@24V | |
| Electromagnetic Features | ||
| EMC Grade: | ECE R10 | |
| Operating Voltage: | 10V~30V | |
| Connector: | DT / AMP/ Cable (Optional) | |
| Mechanical Features | ||
| Size: | 180 X 38 X 55mm | |
| Housing Material: | Aluminium Alloy | |
| Lens Material: | Anti-UV PC | |
| PC Brand | COVESTRO 2407 | |
| Bracket: | 201 or 304 Stainless Steel | |
| IP Rate: | IP67, IP6K9K | |
| Work Temp: | —40~+50°C | |
| So this is Life | ||
| Life Time: | >30,000H | |
