| Model: | E7106 | |
| Functions, Homologation | ||
| Functions: | Low Beam, High Beam, Turn,Side DI, Parking | |
| Homologations | ECE R112, R6, R7, R10 DOT FMVSS 108/SAE J914/ SAE J588/ SAE J222 | |
| Optical & Electric Features | ||
| LED Type: | OSRAM OEM VEHICLE LEDs | |
| Color Temp: | White:5700K-6500k Amber:1600-1800K (Turn) | |
| Energy Consumption: | Low Beam: 15W; High Beam: 15W; Turn Light + Side DI: 2W; Parking: 0.4W | |
| Current Draw: | Low Beam: 1.16A; High Beam: 1.16A; Turn Light + Side DI: 0.17A; Parking: 0.03A | |
| Electromagnetic Features | ||
| EMC Grade: | CISPR 25 Class 3 | |
| Operating Voltage: | 10~30VDC | |
| Connector: | 6 pin DT /AMP /Cable (optional) | |
| Housing Material: | Aluminium Alloy | |
| Lens Material: | Anti-UV PC | |
| PC Brand | COVESTRO 2407 | |
| Bracket: | Stainless Steel | |
| IP Rate: | IP66, IP6K9K | |
| Work Temp: | -40~+50°C | |
| So this is Life | ||
| Life Time: | >30,000H | |
Rapid de-icing with constant 60°c lens
Dark exterior design
Deeper & wider low beam illumination
